Pentax Espio 90MC black (1996)

                                                          For more photos click here!

SPECIFICATIONS

35mm fully automatic lens-shutter with built-in zoom lens and auto flash

Auto film speed setting with 35mm perforated DX-coded film with ISO rating from

25-3200 (1 EV step). Non-DX coded films are automatically set to IS025

24x36mm (Approx. 13x36 in panoramac format)

Auto film loading. Closing the back cover will automatically wind the film to first ex-

posure.

Auto film-winding (single-frame)

Auto film rewinding at the end of roll. Auto stop upon completion of rewinding.

Rewinding time: approx. 20 sec. with 24-exposure film. Rewinding in mid-roll pro-

vided.

Automatic readout of successive frame numbers in ascending order when shoot-

ing. and descending order when rewinding.

Pentax power zoom 38-90mm \/4.5 9.5 5 elements in 5 groups. Angle of view:

59 27

Pentax phase-matching passive five-point autofocus system. Autofocusing range:

0.65m (2.1 ft) - infinity. Maximum magnification: approx. 1/6.3X. Focus lock is

provided Infinity-landscape mode (focus is fixed to infinity). Focus aid illuminator

light is automatically emitted in low tight/ or hard-to-autofocus subject.

Electronic zoom

Programmed AE electronic shutter with speed approx. 1 /30Q - 2 sec. Bulb: \/2

sec-5 min, Electromagnetic release.

Electronic lamp indication. Approx.10 sec. Cancellation after activation is possible.

Standard/panorama switchable, Actual image zoom viewfinder, Viewfinder area:

83%. Magnification: 0.45X (38mm WIDE) - 0 93X(90mm TELE). Diopter adjust-

ment: -3 to + 1 D. AF frame. Picture frame, Close distance compensation frame,

Panorama format picture area. Green lamp lighting: in-focus signal. Green lamp

blinking: When subject is too close and/or hard-to-autofocus subject. Red lamp

lighting: Flash-ready status, Red lamp blinking: Flash being charged.

Exposure control: Programmed auto-exposure control with multi metering system, Range: EV9 -

EV17 at 38mm WIDE, EV1 2 - EV19 at 90mm TELE in Auto or Daylight-Sync mode

(ISO 400), EV4 - EV17 at 38mm, WIDE EV5 -EV19 at 90mm in Slow-Shutter-

Speed mode (ISO 400), Automatic exposure compensation in a backlit situation.

Built-in flash with red-eye reduction mode. Automatic discharge in low lighting and

backlighting situations in auto mode. Flash ON = Day-light Sync/Slow-Shutter-

Speed Sync (up to 2 sec.), Flash-OFF Mode, Bulb-Sync 1/2 sec. - 5min.

0.65 - 8.5m (38mm WIDE), 0.65 - 4.0m (90mm TELE) (ISO 400 film used).

Approx. 5 sec. under Pentax testing conditions.

One 3V lithium battery (CR-2 or the equivalent)

Approx. 8 rolls of 24 exposure film when 50% of shooting uses flash (under Pentax

testing conditions)

1 1 1.5(W) x 61.5(H) x 42(D) mm (4.4"x 2.4"x 1.7") 210g(7.4oz) without battery

Crystal quartz controlled: LCD with digital clock, auto calendar up to 2030. Possible

to imprint both standard and panorama format frames.

"Year, Month and Day". "Day, Hour and Minutes","------blank", "Month, Day and

Year" or "Day, Month and Year".

111.5 (W) x 61.5(H) x42(D)mm (4.4"x 2.4"x 1.7") 210g(7.4oz) without battery

Infrared wireless remote control, 3-seconds delay shutter release. Effective range:

Closer than 5m when projected from the camera's front.

One lithium battery CR1620 (replaced by Pentax Service facility)

22.0(W) x50.0(L) x9.5(D)mm (0.9" x2.0" x0.4"). 9g(0.3oz) including battery
